ACISWAY.CFA.HARVARD.EDU LIVE ACIS DATA: MEAN VALUES, SIGMAS, AND STATUS
ACIS Live: Mean Engineering Data - ACISWAY.CFA.HARVARD.EDU
Web Page Last Updated: Wed Feb 19 12:10:02 UTC 2025
TIME OF LAST DATUM REC'D WAS Wed Feb 19 12:9:35 GMT 2025
DATA WAS IN FMT2 & OBSID 42649 WAS IN PROGRESS
WE ARE CURRENTLY AOS
I last saw data on Wed Feb 19 12:9:47 GMT 2025 (Day 50)

Tracelog File Status is: FRESH


Check the ACIS Limits table


CURRENT ORBITAL INFORMATION

EXPECTED SCHEDULED STATE AT:   Wed Feb 19 12:10:02 UTC 2025 (Day 50)

FP INSTRUMENT
GRATINGS STATUS
OBSID
TLM FORMAT
DITHER STATUS
SCS-155 STATUS
HRC-S ( -99616 )
HETG-IN/LETG-OUT
42649
FMT2
ENAB
CODISAS1

REAL-TIME STATE AT:                       Wed Feb 19 12:9:47 GMT 2025 (Day 50)

FP INSTRUMENT
GRATINGS STATUS
OBSID
TLM FORMAT
DITHER STATUS
SCS-155 STATUS
HRC-S     (-99616.00)
HETG-IN/LETG-OUT
42649
FMT2
ENAB
DISA



SCS-155 Deadman Status at:   Wed Feb 19 12:10:02 UTC 2025 (Day 50)

SCS-155 Deadman
Description
Latest Real Time Contact State
COSCS155S - 9 daySCS-155 Active Status
DISA




CURRENT RADIATION ENVIRONMENT ON CHANDRA

Start Time Wed Feb 19 12:9:32 GMT 2025
End Time Wed Feb 19 12:4:37 GMT 2025


HRC RADMON
Description
MEAN VALUE
SIGMA OF THE MEAN
SCS107 Limit
MCPTOT_B - 9 dayuncalibrated MCP total rate
19.30
0.98
30
SHIELD_B - 9 dayuncalibrated shield rate
21.60
0.60
245

LATEST ORBITAL FLUENCE DATA AT:   Wed Feb 19 12:10:02 UTC 2025

ALTITUDE
LATEST ACIS FLUX (ACE P3 CHANNEL)
ACIS FLUENCE (ACE P3 CHANNEL)
28924 km A
0.00e+00
0.000e+00



ACE 24 Hour EPAM FLUX AND FLUENCE DATA AT:   Wed Feb 19 12:10:02 UTC 2025

ALTITUDE
Plot
LAST P3
LAST Att. P3
ORB. Att. P3 FLU
ORB. Frac.
YEAR Att P3 FLU
28924 km A
24hr Plots
1.090e+01
0.000e+00
2.218e+06
0.872
4.074e+08

Date of Last P3 Data Point:   2025:049:21:02:55.00


Description of ACE 24 Hour table header items. Start Time: Wed Feb 19 12:9:34 GMT 2025




Target and Actual Quaternions:   Wed Feb 19 12:10:02 UTC 2025


MSID
Description
Value
TimeTime of the last value
Wed Feb 19 12:9:34 GMT 2025
AOTARQT1TARGET ATTITUDE QUATERNION 1
-0.3864429000
AOTARQT2TARGET ATTITUDE QUATERNION 2
-0.4450084600
AOTARQT3TARGET ATTITUDE QUATERNION 3
0.0924955610
--------TARGET ATTITUDE QUATERNION 4
---------
AOATTQT1ACTUAL ATTITUDE QUATERNION 1
-0.3864581000
AOATTQT2ACTUAL ATTITUDE QUATERNION 2
-0.4450204400
AOATTQT3ACTUAL ATTITUDE QUATERNION 3
0.0925403980
AOATTQT4ACTUAL ATTITUDE QUATERNION 4
0.8025230200



SIM AND FOCUS POSITIONS



Start Time: Wed Feb 19 12:9:10 GMT 2025
End Time: Wed Feb 19 12:9:10 GMT 2025

MSID
DESCRIPTION
LAST VALUE
[37]TSCPOSSIM TT Position
-99616.00 / -1.00
[37]FAPOSSIM FA Position
-467.00 / -1.00
4HPOS[AB]ROHETG Angle
5.59 / 5.96
4LPOS[AB]ROLETG Angle
76.84 / 76.09



SIM Motor Overcurrent & Stall Cntrs
Start Time: Wed Feb 19 12:4:18 GMT 2025
End Time: Wed Feb 19 12:9:13 GMT 2025

MSID
DESCRIPTION
MEAN VALUE
SIGMA OF THE MEAN
# OF FRAMES
3SMOTOCSIM Motor Overcurrent Cntr
0.00
0.00
10
3SMOTSTLSIM Motor Stall Cntr
0.00
0.00
10




ELECTRICAL DATA
ACIS DPA
Start Time: Wed Feb 19 12:4:37 GMT 2025
End Time: Wed Feb 19 12:9:32 GMT 2025

MSID
DESCRIPTION
MEAN VALUE
SIGMA OF THE MEAN
# OF FRAMES
1DP28AVO - 9day DPA +28V Input A
25.94
0.04
10
1DP28BVO - 9day DPA +28V Input B
26.15
0.04
10
1DPICACU - 9day DPA Input Current A
0.79
0.00
10
1DPICBCU - 9day DPA Input Current B
0.97
0.00
10
DPA A POWER - 9day 1DP28AVO*1DPICACU
20.49
0.03
NA
DPA B POWER - 9day 1DP28BVO*1DPICBCU
25.37
0.04
NA
1DPP0AVO - 9day DPA +5V Analog A
5.19
0.00
10
1DPP0BVO - 9day DPA +5V Analog B
5.21
0.00
10



ACIS DEA
Start Time: Wed Feb 19 12:6:35 GMT 2025
End Time: Wed Feb 19 12:9:19 GMT 2025

DEA A-Side MSID
DESCRIPTION
MEAN VALUE
SIGMA OF THE MEAN
# OF FRAMES
DEA B-Side MSID
DESCRIPTION
MEAN VALUE
SIGMA OF THE MEAN
# OF FRAMES
1DE28AVO - 9day DEA +28V Input A
26.01
0.03
10
1DE28BVO - 9day DEA +28V Input B
26.16
0.02
10
1DEP3AVO - 9day DEA +28V Analog A
30.57
0.02
10
1DEP3BVO - 9day DEA +28V Analog B
0.24
0.02
10
1DEP2AVO - 9day DEA +24V Analog A
24.54
0.02
10
1DEP2BVO - 9day DEA +24V Analog B
0.23
0.01
10
1DEP1AVO - 9day DEA +15V Analog A
15.29
0.01
10
1DEP1BVO - 9day DEA +15V Analog B
0.15
0.01
10
1DEP0AVO - 9day DEA +6V Voltage A
6.08
0.00
10
1DEP0BVO - 9day DEA +6V Voltage B
0.05
0.00
10
1DEN0AVO - 9day DEA -6V Voltage A
-6.13
0.01
10
1DEN0BVO - 9day DEA -6V Voltage B
-0.14
0.01
10
1DEN1AVO - 9day DEA -15V Voltage A
-15.27
0.01
10
1DEN1BVO - 9 day DEA -15V Voltage B
-0.32
0.02
10
1DEICACU - 9 day DEA Input Current A
0.91
0.16
10
1DEICBCU - 9 day DEA Input Current B
0.00
N/A
10
DEA A POWER - 9day 1DE28AVO*1DEICACU
23.67
4.16
NA
DEA B POWER - 9day 1DE28BVO*1DEICBCU
0.00
N/A
N/A

Top


ACIS-AT-A-GLANCE STATUS LIGHTS
HW AND SW LEDS
HW End Time: Wed Feb 19 12:8:32 GMT 2025
SW End Time: Wed Feb 19 12:8:32 GMT 2025
ACIS MECH
End Time: Wed Feb 19 12:9:7 GMT 2025




MSID
1STAT[7654]ST    STATUS -->
1STAT7STRED (0) -> FIFO EmptyGREEN (1) -> FIFO Not Empty
1STAT6STRED (0) -> FIFO FullGREEN (1) -> FIFO Not Full
1STAT5STRED (0) -> BEP Held In ResetGREEN (1) -> BEP Not In Reset
1STAT4STRED (0) -> BEP A SelectedGREEN (1) -> BEP B Selected
MSID
1STAT[3210]ST    STATUS -->
1STAT3STRED (0) -> BEP Code InitializedGREEN (1) -> BEP Code Initializing
1STAT2STRED (0) -> Watchdog BootGREEN (1) -> Normal Boot
1STAT1STRED (0) -> Science ActiveGREEN (1) -> Science Idle
1STAT0ST0 or 1: BEP SW Is RunningBit Toggles Every 64s

MSID
DESCRIPTION
STATUS
1MDBUAONDoor Enable A
1MDBUBONDoor Enable B
1MODRAOPDoor Open Drive A
1MODRBOPDoor Open Drive B
1MCDRACLDoor Close Drive A
1MCDRBCLDoor Close Drive B
1VVDBAONVent Valve Enable A
1VVDBBONVent Valve Enable B
1VVODAOPVent Valve Open Drive A
1VVODBOPVent Valve Open Drive B
1VVCDACLVent Valve Close Drive A
1VVCDBCLVent Valve Close Drive B
1LVDBAONL V Enabled A
1LVDBBONL V Enabled B




















Top

ACIS AT A GLANCE
End Time: Wed Feb 19 12:9:7 GMT 2025
ACIS AT A GLANCE
End Time: Wed Feb 19 12:9:7 GMT 2025



MSID
DESCRIPTION
STATUS
1DPPSAXDPA POWER SUPPLY EN/DIS A
1DPPSADPA POWER SUPPLY ON/OFF A
1DPPSBXDPA POWER SUPPLY EN/DIS B
1DPPSBDPA POWER SUPPLY ON/OFF B
1DEPSAXDEA POWER SUPPLY EN/DIS A
1DEPSADEA POWER SUPPLY ON/OFF A

MSID
DESCRIPTION
STATUS
1DAHTAENDA HTR EN/DIS A
1DAHTAONDA HTR ON/OFF A
1DAHTBENDA HTR EN/DIS B
1DAHTBONDA HTR ON/OFF B
1DABOAENDA BAKE OUT EN/DIS A
1DABOAONDA BAKE OUT ON/OFF A
1DABOBENDA BAKE OUT EN/DIS B
1DABOBONDA BAKE OUT ON/OFF B
1DE28AOCDEA POWER SUPPLY +28V Over-Current Protection
1DE28BOCDEA POWER SUPPLY +28V Over-Current Protection
1DEMVAOCDEA POWER SUPPLY Multi-V Over-Current Protection
1DEMVBOCDEA POWER SUPPLY Multi-V Over-Current Protection
1DPCPAOCDPA POWER SUPPLY Over-Current Protection
1DPCPBOCDPA POWER SUPPLY Over-Current Protection
1DEPSBXDEA POWER SUPPLY EN/DIS B
1DEPSBDEA POWER SUPPLY ON/OFF B
























Top


THERMAL DATA

THERMAL CONTROL DATA: SIDE A and B
Start Time: Wed Feb 19 12:6:36 GMT 2025
End Time: Wed Feb 19 12:9:20 GMT 2025

MSID
DESCRIPTION
MEAN VALUE
SIGMA OF THE MEAN
# OF FRAMES
1CRAT - 9 day Cold Radiator Temp A
-113.54
0.00
10
1CRBT - 9 day Cold Radiator Temp B
404.81
0.00
10
1WRAT - 9 day Warm Radiator Temp A
-77.11
0.00
10
1WRBT - 9day Warm Radiator Temp B
-77.11
0.00
10
1DPAMYT - 9 day DPA -Y Panel Temp (RT810)
7.11
0.00
10
1DPAMZT - 9 day DPA -Z Panel Temp (RT830)
10.56
0.00
10
1DEAMZT - 9 day DEA -Z Panel Temp (RT830)
5.55
0.00
10
1SSPYT - 9 day Suppt Structure +Y Panel Temp (RT810)
11.68
0.05
10
1SSMYT - 9 day Suppt Structure -Y Panel Temp (RT811)
12.41
0.15
10
1PDEAAT - 9 day PSMC DEA Power Supply Temp A
20.81
0.34
10
1PDEABT - 9 day PSMC DEA Power Supply Temp B
14.97
0.59
10
1PIN1AT - 9 day PSMC Temp 1A
71.84
0.00
10
1CBAT - 9 day Camera Body Temp A
-59.89
0.00
10
1CBBT - 9 day Camera Body Temp B
-57.42
0.00
10
1DACTBT - 9 day DA Collimator-Top Temp B
-17.83
0.25
10

ISIM TEMPERATURES
Start Time: Wed Feb 19 12:6:59 GMT 2025
End Time: Wed Feb 19 12:9:26 GMT 2025

MSID
DESCRIPTION
MEAN VALUE
SIGMA OF THE MEAN
# OF FRAMES
3TSMYDPT - 9 day -Y Shell (facing DPA)
-57.23
0.00
10
3TSPYFET - 9 day +Y Shell (facing HRC)
-52.24
0.00
10
3TSPZDET - 9 day +Z Shell (facing DEA)
-12.33
0.00
10
3TSPZSPT - 9 day +Z Shell (facing SS)
-2.36
0.00
10
3TSMXSPT - 9 day -X Shell (facing SS)
-39.77
0.00
10
3TSMXCET - 9 day -X Shell (facing HRC)
-87.16
0.00
10
3RCTUBPT - 9 day +X SIM (RCTU base)
4.41
0.00
10
3TTACS1T - 9 day TT at -Y foot
-7.71
0.00
10
3TTACS2T - 9 day TT at +Y foot
-12.35
0.04
10
3TTACS3T - 9 day TT at +Z foot
-13.06
0.06
10


Top


HEATER DATA
ACIS DA
Start Time: Wed Feb 19 12:4:33 GMT 2025
End Time: Wed Feb 19 12:9:28 GMT 2025

MSID
DESCRIPTION
MEAN VALUE
SIGMA OF THE MEAN
# OF FRAMES
1DAHHAVO - 9 day DA Housing Htr +28V Input A
0.00
0.00
10
1DAHHBVO - 9 day DA Housing Htr +28V Input B
0.00
0.00
10
1DAHAVO - 9 day Detector Assy. Htr Voltage A
0.00
0.00
10
1DAHBVO - 9 day Detector Assy. Htr Voltage B
0.00
0.00
10
1DAHACU - 9 day Detector Assy. Htr Current A
0.00
0.00
10
1DAHBCU - 9 day Detector Assy. Htr Current B
0.00
0.00
10
HTR A POWER - 9day 1DAHAVO*1DAHACU
0.00
NA
NA
HTR B POWER - 9day 1DAHBVO*1DAHBCU
0.00
NA
NA
1DAHAT - 9day Detector Assy. Housing Temp Offset A
22.80
0.44
10
1DAHBT - 9day Detector Assy. Housing Temp Offset B
8.20
0.44
10

Top


MECHANISMS' DATA
ACIS DOOR
Start Time: Wed Feb 19 12:6:37 GMT 2025
End Time: Wed Feb 19 12:9:21 GMT 2025

* MSID *
DESCRIPTION
MEAN VALUE
SIGMA OF THE MEAN
# OF FRAMES
1DACTATDoor Angle Potentiometer
68.90
0.00
10
1OAHAT - 9 day Open Actuator Housing Temp A
-27.60
0.00
10
1OAHBT - 9 day Open Acutator Housing Temp B
-30.10
0.00
10
1MAHOATDoor Open Actuator Temp A
439.84
0.95
10
1MAHOBT Door Open Actuator Temp B
438.70
0.87
10
1MAHCATDoor Close Actuator Temp A
439.27
0.93
10
1MAHCBT Door Close Actuator Temp B
439.84
0.95
10


Top
